Precision Thermometer
For calibrating flat bed incubators and workstations
The ASL WIKA CTH7000 precision thermometer is a resistive type thermometer with an accuracy of ±0.02 compared to common used thermo couple types with accuracy of ±0.1.
The resolution of the ASL WIKA CTH7000 is 0.001°C needed for a correct calibration of your flat bed incubator.
- System accuracies better than 0.035°C over the full operating range.
- Stability: <0.005°C per year.
- Statisical analysis- average, max/min and standard deviation.
- Internal logging, software and USB communication
Product Specifications
| Accuracy | ASL WIKA CTH7000 only: ±0.02°C (±20mK) |
| Resolution | 0.001°C |
| Probe types |
Pt100 and Pt25 resistance thermometers plus NTC
thermistors. Thermometer input2 x 5 pin industrial DIN socket with screw lock to connecting plug, accepting both normal and SMART probes |
| Operating conditions |
Full specification range: +15°C to +25°C Full operating range: 0°C to +40°C <80%RH non-condensing |
| Dimensions (LxDXW) | 232x97x53 mm nominal |
| Weight | 500 g (1.1 lbs) |
Order Codes
| Order Number | Description |
|---|---|
| 11010 | F100 Thermometer - 2 input |
| 11010P1 | F100 Thermometer, calibrated/1 probe - Calibrated with 1 probe |
| 11010P2 | F100 Thermometer, calibrated/2 probes - Calibrated with 2 probes |
| 11006 | STS Sensor - Temperature Sensor for validation |
| 22306 | Pin Sensor - F100 probe for incubator G185ST |
